Massey Ferguson MF RK Series
Maximise your efficiency and cut repairs and downtimes during forage harvesting season with Massey Ferguson’s MF RK range of rakes.
You won’t find a better rake than within Massey Ferguson’s MF RK Series. Offering high performance, easy handling and an extremely long-lasting design, they come with a single rotor, two or four-rotor, two-rotor central delivery, two-rotor side delivery, and four-rotor central delivery, depending on your requirements.
There are many benefits to owning an MF RK, including patented steering and fully cardanic rotor suspension, plus tangentially-arranged tine arms for optimum raking quality. Simpler to service to due several well-considered components, Massey Ferguson rakes also come with overload protection fitted to their power trains, preventing costly repairs and long downtimes.
Modern, Proven Design
- Constructed of spheroidal graphite cast iron, the cam track – with its optimised shape – ensures smooth running and quick, precise lifting of the tines.
- Large dimensioned drive unit.
- Aluminium alloy, precision-manufactured tine arm housing.
- Tangentially-arranged tine arms for best raking quality, and higher working speeds – even in poor weather.
- STEERGUARD, a patented steering system operating within the frame, provides reliable, safe and accurate steering movement.
- Patented, fully cardanic rotor suspension gives perfect ground adaptation in all conditions.
Long Service Life
- By choosing a rake from Massey Ferguson, you’re guaranteed a long service life – the enclosed rake head design guards all of the components from dirt and dust.
- Special bolt-on connection for the rake head means that the bolts are not subjected to any shearing effect, and results in precise centering and stability for a long service life.
- Tine arms can be replaced individually as needed, without having to take apart the rake socket.
Specifications
| Model | MACHINE DESIGNATION(M) | WORKING WIDTH(M) | NUMBER OF ROTORS | Product Brochure |
|---|---|---|---|---|
| MF RK 361 DSR | 3.60 | 3.60 | 1 | Download |
| MF RK 341 DN | 3.40 | 3.40 | 1 | Download |
| MF RK 361 DN | 3.60 | 3.60 | 1 | Download |
| MF RK 381 DN | 3.80 | 3.80 | 1 | Download |
| MF RK 391 DN | 3.85 | 3.85 | 1 | Download |
| MF RK 421 DN | 4.20 | 4.20 | 1 | Download |
| MF RK 451 DN | 4.50 | 4.50 | 1 | Download |
| MK RK 451 TR | 4.50 | 4.50 | 1 | Download |
| MF RK 702 TR-SDX | 7.00 | 7.00 | 2 | Download |
| MF RK 662 SD-TRC | 6.65 | 6.65 | 2 | Download |
| MF RK 772 SD-TRC | 7.70 | 7.70 | 2 | Download |
| MF RK 842 SD-TRC | 8.40 | 8.40 | 2 | Download |
| MF RK 842 SD-TRC PRO | 8.40 | 8.40 | 2 | Download |
| MF RK 662 TRC | 6.60 | 6.60 | 2 | Download |
| MF RK 762 TRC | 7.60 | 7.60 | 2 | Download |
| MF RK 802 TRC | 8.00 | 8.00 | 2 | Download |
| MF RK 802 TRC PRO | 8.00 | 8.00 | 2 | Download |
| MF RK 1002 TRC | 10.00 | 10.00 | 2 | Download |
| MF RK 1002 TRC PRO | 10.00 | 10.00 | 2 | Download |
| MF RK 1254 TRC EC | 12.50 | 12.50 | 4 | Download |
| MF RK 1254 TRC Gen2 | 12.50 | 12.50 | 4 | Download |
| MF RK 1254 TRC PRO Gen2 | 12.50 | 12.50 | 4 | Download |
| MF RK 1404 TRC PRO Gen2 | 14.00 | 14.00 | 4 | Download |
